SRP Dual { 0} Lu Module Rotary Rotary: Doxalinu Àdduna ngir xam-xam bu leer ak bu mujj
Ingénieur ngir aplikaasioŋ yi soxla jafe-jafe yu bari ak jafe-jafe
Ingénieur yu bees
▌n
2disk →108Nm torque 108Nm(SRP63 @6bar)
○ Tanne 90 degre wala 180 degrengir liggéey- optimesé
2di dindi tube bi ci biti (IP64 sertifiye)
▌
|
Royuwaay |
A3 ma @6bar |
Diisaay |
Time |
tooñ |
Jub |
|
SRP30 |
10.5 Nm |
2.4kg |
1.0s/1.2s |
90 degre / 180 degre |
±0.05 degre |
|
SRP40 |
22 Nm |
4.36kg |
1.2s/1.5s |
90 degre / 180 degre |
±0.07 degre |
|
SRP50 |
49.5 Nm |
9.1kg |
1.6s/1.8s |
90 degre / 180 degre |
±0.07 degre |
|
SRP63 |
108 Nm |
26kg |
1.9s/2.1s |
90 degre / 180 degre |
±0.1 degre |
Man-mani yu doy waar
► Center Bore: Ø10-25mm ngir mëna daw ci kable
► Cushioning hydraulique: absorption choc buñ mëna jëfandikoo
► Ligg
► Range: 3-8 bar (4.5-8 bar ngir SRP63)
► Déggoo ci jawwu ji: 196-990 L/min
► Range tampérature: 5-60 degre
Njàngat ci biir ngërëm
Asammbale ci wàllu pajum
Jubluwaay bu am solo ci ISO Class 5
Jumtukaayu sterilisasioŋ sterilisation
Kañ
Kontaanu semiconductër
Casette 180 degre ngir def ñaari - ci wet
Déggoo bu am ci vocaux de chambre
Etasion yu am solo yi ci wàllu nataal
Doxal ñam
Jubluwaayu conteneur emballage équipe
Sistemu defar produit bakery
Clean-i-Place (CIP) bu méngoo
Otogramu elektronik
Panelu PCB 90 degre indexing ngir saytu pasteeru bànk
Module ci modulu modle bi
Ndaje dëkkuwaayi konner yi
Njariñ yu méngoo
Risk buy Kontamination zéro: Routing interne dafay tere nit ñi
Angle Flexibility: Waxtu yi dañuy jëfandikoo 90 degre ci 180 degre
Waxtaan: 0.05 degre ci 1.0s ci diiru cycle (SRP30-90)
Aar offload: Fi ñu mëna taxaw ci wàllu mekanik ak ± 3 degre
Njariñu sàmmonte: Hard-nanodized aluminium dafay ànd ak ay produit yu ñuy raxas ci biir suuf si.
Tëjteel
SRP Rotary Module dafay soppi anam wi ñu koy defeeñaari sistem dawal dawal, di joxeliggéey {08Nm)akMicroci environmaa yu set ak yu liggéey. Revolusioŋ bi ci biir revolusioŋ bi dafay dindi risku contamination yi ci wàllu pajum ak semi-conducteur ci noonu lañuy joxe aar IP64 ci environmaa bi. Rotation 90 degre / 180 degre dafay tax ñu mëna defar liggéey bu baax, ak cushing hydraulique ngir mëna yëngu- positionnement. Ngir ingenieur yiy saytu otomatise di xeex jafe-jafe yi ci yor fiil yi wala contamination yu set, SRP dafay joxe liggéey bu amul benn njariñ ci anamu mekanik.
Fàww ci anam wu jaar yoon, SRP dafay joxe position angular bu amul benn sikk ngir Industry 4.0's yi gëna am njariñ.
